Access Control System with Remote Control – 600lbs Magnetic Door Lock Kit, 12V Fail Safe NC Mode, Secure & Easy DIY Installation for Smart Home Entry (K8-600LBS Remote Control Lock Kit)

Product description

Entry Management System with Distant Management

DESCRIBE

The primary function of this package is that it lets you open the door just by urgent the wi-fi RF distant as a substitute of transferring to the door bodily when somebody visits.

The operate of the receiver is that when the ability is on, the magazine lock of your package is locked and once you press the distant the magazine lock will unlock briefly to open the door.

0/5/10 seconds locking delay time adjustable, default is 5 seconds.

An exit button is included on this magnetic lock system package, and you might exit from indoors simply by pushing it as soon as.

ELECTRIC MAGNETIC LOCK

Enter Voltage: 12VDC

Present: 520mA

Holding Power: 600lbs (280kg)

Fail Protected mode: Unlocked whereas energy is eliminated

Cowl End: Anodized aluminum

Lock End: Zinc

Armature Plate End: Zinc

Dimension (L x W x H): 250 x 49 x 25 (mm) / 9.84x 1.93 x 0.98 (inch)

Armature Plate Dimension (L x W x H): 180 x 38 x 11(mm) / 7.09 x 1.50 x 0.43 (inch)

1200lbs Magnetic Lock

Cowl End: Anodized aluminum

Lock End: Zinc

Armature Plate End: Zinc

Enter Voltage: 12V DC

Present: 12V/480mA

Holding: 500kg / 1200Lbs

Fail protected: Unlocked whereas energy is eliminated (NC Mode)

Dimension (L x W x H): 265 x 75 x 39 (mm) / 10.43x 2.95 x 1.54 (inch)

Armature Plate Dimension (L x W x H): 185 x 60 x 13(mm) / 7.28 x 2.36 x 0.51 (inch)

REMOTE CONTROL

Voltage: 12VDC

Frequency: 433MHz

RF channels: One

Distant Transmitter Help: Max. 40

DC Encoding Sort: Studying code

Adjustable Locking Delay: 0/5/10sec

Dimension (L x W x H): 92 x 46 x 25 (mm) / 3.62x 1.81 x 0.98 (inch)

REMOTE TRANSMITTER

Working voltage: 6VDC

Working Present: 3mA

Powerd by: 2pcs CR2016/3V batteries (Constructed-in)

Service Lifetime of the Battery: 50000 cycles assessments

Transmitting Frequency: 433MHZ

Buton: 2

Enclosure Materials: ABS Plastic

Dimension (L x W x H): 60 x 28 x 11 (mm) / 2.36x 1.1 x 0.59 (inch)

POWER ADAPTER

Sort: 12V 2A Energy Provide Wall Charger

Enter: AC100V-240V 50/60Hz

Max Output: DC12V / 2A (2000mA)

AC Wire Size: 2.95 toes (0.9 meters)

Wire Sort: 22AWG

Dimension (L x W x H): 75 x 40 x 30 (mm) / 2.95x 1.57 x 1.18 (inch)

PUSH TO EXIT BUTTON

Mechanical Life: 500000 assessments

Present Score: 3A@36VDC Max.

Output Contact: NO/COM

Working Temperature: 14℉~131℉ (-10℃～55℃)

Working Humidity: 0-95% (relative humidity)

Dimension (L x W x H): 92 x 46 x 25 (mm) / 3.62x 1.81 x 0.98 (inch)

Magnetic Buzzer

Rated Voltage: 12V

Rated Present (MAX): ≤12mA

Min Sound Output at 10cm:≥95dB

Resonant Frequency:3000 ±500Hz

Working Temperature：-20~+70℃ （-4-158）℉

Enclosure Materials: ABS Plastic

Dimension (L x W x H): 46 x 30 x 15 (mm) / 1.81x 1.18 x 0.59 (inch)

PACKAGE LIST

1 x Electrical Magnetic Lock

1 x Distant Receiver

2 x Distant Transmitter

1 x Push to Exit Button

1 x Energy Adapter

1 x English Person Guide

1 x Magnetic Buzzer

600lbs Magnetic Lock – Final Safety: The 600lbs magnetic door lock ensures a powerful and dependable holding drive, offering superior safety to stop unauthorized entry. Good for houses and places of work the place security is a prime precedence.
Fail Protected NC Mode – Automated Unlock in Energy Outage: Designed with a fail-safe NC (usually closed) mode, this method robotically unlocks throughout energy outages, guaranteeing you are by no means locked out in an emergency state of affairs. Supreme for security compliance in residential and business settings.
Distant Management Entry – Keyless Comfort: Features a wi-fi distant management that enables for handy, keyless entry with only a press of a button. Get pleasure from quick access from as much as 50 toes away—no extra fumbling with keys or conventional locks.
Simple DIY Set up – No Skilled Wanted: Comes with clear set up directions and all mandatory {hardware} for fast and hassle-free setup. The system may be simply put in on each picket and steel doorways, making it an excellent DIY venture.
Good House Suitable – Supreme for Fashionable Dwelling Good for sensible houses and trendy safety techniques, this entry management system can seamlessly combine together with your present residence automation setup, enhancing each safety and comfort for on a regular basis use.
